Malfunctions in driving mode
7.5 Fuses
Operating Manual GMK6300L 3 112 xxx en 7 - 23
xx.xx.xxxx
Group F6
Group F7
Group F8
s
Designation Amperage (A) Function
F6/1 5
Left-hand side marker lights and parking
light
F6/2 10
Right-hand side marker lights
1)
and
parking light
F6/3 10
marker light and tail lamps, left-hand
instrument lighting
F6/4 5 Right-hand marker light and tail lamps
F6/5 5 Left full-beam headlight
F6/6 5
Right-hand full beam headlight, indicator
lamp for full beam headlight
F6/7 5 Headlight, left
F6/8 5 Headlight, right
Designation Amperage (A) Function
F7/1 2 Control unit ESX 4
F7/2 5
ESX 4 sensors,
Fuse monitoring
F7/3 20 Control unit ESX 4
F7/4 2 Control unit ESX 5
F7/5 5
ESX 5 sensors,
Fuse monitoring
F7/6 20 Control unit ESX 5
F7/7 7.5 Fog light
1)
F7/8 7.5 Rocker
1)
Additional equipment
Designation Amperage (A) Function
F8/1 5 Fixed voltage controller 5 V
