Maytag MFR40PD - DL1 - Door Lock Connector; T1 - Temperature Sensor; L1 - Debit Card Reader; RS485 - Serial COM1

8-13
DL1 - DOOR LOCK CONNECTOR
Pin Wire Component
D1 Grey Bimetal
D2 #38 Bimetal
D3 #49 Lock Coil
D9 #10 Lock Coil
D4 #44 Door Closed Switch
D10 #45 Door Closed Switch
D6 Purple Door Locked Switch
D12 Red Door Locked Switch
D7 #50 Unlock Coil
D8 #11 Unlock Coil
D5 Not Used
D11 Not Used
T1 - TEMPERATURE SENSOR
Pin Wire
T1 White
T2 Black (shield)
T3 Brown
L1 - DEBIT CARD READER
Pin Wire
L1 Available 2
L2 Available 1
L3 Enable 1
L4 Enable 2
L5 +24VDC
L6 Ground
RS485 - SERIAL COM1
Pin Wire
C1 RDB/SDB
C2 SG
C3 RDA/SDA
TTL Y1 - SERIAL COM2
Pin Wire
Y1 +5VDC
Y2 RXD
Y3 GND
Y4 TXD
Y5 SCK
D1 - MC4 12VDC TAP
MC5 24VDC TAP
Pin Wire
D1
D2
A1 - COIN ACCEPTOR
Pin Wire Component
A1 Red +12VDC (MC4)
A1 Red +24VDC (MC5)
A2 GND/
Blue
Electronic Coin - Black
A3 Green 1 Electronic Coin - White
A4 Green 2 Electronic Coin - Brown
A5 Not Used
A6 Orange Service Switch
A7 Purple Vault Switch (CSA)
A8 Not Used
A9 Jumper to DL6 (MC4)
A9 Jumper to DL7 (MC5)
A10 Not Used
