Sleeve
Sleeve
Basket Stabilizer
Lever bar
Cup
Push bushing
Push bushing
Bearing cup 2
Bearing cup 1
Remove seal sleeve Removal tool
Bearing Cup 2
Bearing cup 1
Tool Set Code H965 518877
Valid for :
• 6 - 7 - 10 - 13 - 18 - 27 - 35 kg / 18 - 25 - 30 - 40 - 60 - 80 lb and,
• 22 kg / 50 lb with ball bearing 63- series at back side.
Date: 22 jun 2006
OPERATION TOOL PART
6 - 7 kg
18 lb
10 kg
25 lb
13 kg
30 lb
18 - 22 kg
40 - 50 lb
27 kg
60 lb
35 kg
80 lb
1
Removing pulley
Remover 518929 518936
Bolt 518933 518940 518942 518941
514759
2 Trunnion removal
Puller standard puller 518851
Bolt 518933 518940 518942 518941
N/A 518919 N/A 518919 N/A
Tub support N/A 518918 518963 518917
Guidance rods N/A 518861
Drum guide N/A 518862
3
Bearings removal General push and pull tool 518878 N/A
Removal of bearing 1
518904 518902 518892 518897 518906
Squeeze out part 1 518905 518893 518894 518983
Removal of bearing 2
518892 518903 518895 518898 518900 518909
Squeeze out part 2 518893 518894 518899 518901 518984
518896 518905 518905 518896 518905
4
Remove counter ring Lever N/A 514760
N/A 518970 N/A
5
Bearings assembly
General push and pull tool 518878
518891 518890 518883 518884 518955
518890 518889 518884 518885 518886 518956
518896
6
Assembly of axial seal Push-in tool 518962 518961 518960 N/A 518858
Centering of axial seal Center thorn 518953 518954 N/A
7
Assembly of radial seals
in seal holder
General push and pull tool N/A 518878 N/A
Cup N/A 518887 N/A
Center part N/A 518888 N/A
8
Assembly of radial seal
holder in bearing housing
General push and pull tool N/A 518878 N/A
N/A 518888 N/A
N/A 518884 N/A
9
Assembly of radial seal
ring
General pull tool N/A 518950 N/A
N/A 518981 N/A
10 Trunnion
General pull tool 518950
Support part 518916 518915 518914 518913 518869
12
Pulley assembly General pull tool 518950
NOTE: Push bushing may be referred to as a Thorn.
