4-14
If necessary, hold the head of the carriage
bolt on the front side of the door with a pair
of locking pliers.
Remove the two carriage bolts.
Remove the lever shaft from the latch.
Pull the handle through the hole in the door
to the inside of the door to remove it.
NOTE: The most common reason to replace
the handle is because the latch end gets
badly burred, which affects the door locking.
5.
6.
7.
8.
REMOVE DOOR HANDLE & LATCH
Open the washer door.
Release the spring pin on the inside of the
door latch. The spring has a limiter on it
which keeps the spring from being pushed
up to high which could jam the door.
Use a 2.5mm hex key to remove two set
screws that secure the handle cover to the
handle.
Remove two nuts from the inner rim of the
door.
1.
2.
3.
4.
Two 2.5mm
Set Screws
2 Nuts
Spring Pin
Spring
Limiter
Lever Shaft
To Next Page
