Page 105
Appendix| EtherCAT Documentation
capaNCDT 6200
Object 1000h: Device type
1000 VAR Device type 0x00200000 Unsigned32 ro
Provides information about the used device profile and the device type.
Object 1001h: Error register
1001 VAR Error register 0x00 Unsigned8 ro
Object 1008h: Manufacturer device name
1008 VAR Device name DT6230 Visible String ro
Object 1009h: Hardware version
1009 VAR Hardware version V x.xxx Visible String ro
Object 100Ah: Software version
100A VAR Software version V x.xxx Visible String ro
Object 1018h: Device identification
1018 RECORD Identity
Subindices
0 VAR Number of entries 4 Unsigned8 ro
1 VAR Vendor ID 0x0000065E Unsigned32 ro
2 VAR Product code 0x003EDE73 Unsigned32 ro
3 VAR Revision 0x00010000 Unsigned32 ro
4 VAR Serial number 0x009A4435 Unsigned32 ro
The article number is deposit in the product code, the serial number of the sensor in serial number.
