Installation and Assembly
capaNCDT 6200
Cylindrical sensors with thread
CSE05/M8 CSE1,25/M12
14.0
17.0 (.67)
+0.1
-0.2
13.4 WS6
18.5
22.0 (.87)
17.6
3.0
(.12)
ø5.7
ø6.0
(.24 dia.)
ø9.7
ø10
ø10.4 (.41 dia.)
M8x0.5
M12x1
4.0
(.16)
WS10
Connector side
Dimensions in mm
(inches)
Active measuring
surface sensor
Dimensional drawings
of other sensors are
available on request.
