MICRO-EPSILON CS02 User Manual

Page 30
Installation and Assembly
capaNCDT 6200
15.5 (.61)
ø3
(.12)
ø2.2
(.09)
0.1
(.003)
20 (.79)
5
(.20)
1.6
ø4
(.16)
ø2.2
(.09)
appr. 9.4
(.37)
15.5 (.61)
20 (.79)
7.6
appr. 37 (1.46)
CSH2FL-CRmx
(.30)
(.06)
ø2.2
(.09)
0.1
(.003)
5(.20)
2.2
ø4
ø2.2
(.09)
appr. 9.4
(.37)
20 (.79) 25 (.98)
appr. 37 (1.46)
20 (.79)
25 (.98)
ø3
(.12)
7.6
CSH3FL-CRmx
(.09)
(.16)
(.30)
Cable length 1.4 m visible (incl. crimp sleeve)
Dimensions in mm (inches), not to scale
