Page 92

Appendix| Accessories, Service

capaNCDT 6200

SWH.OS.650.CTMSV

SW12

ø8.8

(.35)

ø14

(.55)

(.35)

(.08)

34 (1.34)

max. 17

(.67)

M10x0.75

Vacuum feed through,

Max. leak rate 1x10e-

mbar · l s

-1

Compatible with connector type B
