106 Panel Functions
_________________________________________________________________________________________
_________________________________________________________________________________________
Microplex logiJET TC8 Edition 1.2
3. Now let the printer measure the label length automatically:
use the AutoMeasurement panel function for this
logiJET TC8 \ Paper Menu \ Paper Size \ Paper Length \ Auto.Measurement
4. Check if there is a difference between your measured label length and the
5. If there is a significant difference, you have to calculate the slip correction
Nominal label length Printer measured label length
Printer measured label length
For example:
If you measured a nominal label length of 210 mm and the print
measurement shows 205.5 mm:
The slip correction setting needs to be altered by -20.
Heavily simplified: if the printout is too long, the slip correction has to be reduced.
6.
logiJET TC8 \ Engine \ Slip Menu \ Slip Correction
The printer shows the currently setting value, please add your new
slip correction (considering the signs).
In continuation of the example above:
If the printer shows the current slip correction value 35 you have to
add the value -20. The result is: reduce the slip correction to 15.
More details on setting the Slip Correction are described in the previous section.
