Microplex LOGIJET TC8 - Characteristics of the Logijet TC8

24 Basic Operation Sequences
_________________________________________________________________________________________
_________________________________________________________________________________________
Microplex logiJET TC8 Edition 1.2

If the panel settings above shall be effective permanently (that
means they do not have to be put in again after a printer
OFF/ON) the setting values can be saved permanently by
operating the ENTER key two times.
An output of the current setting values can be generated using
8).
Detailed information on the operations above and to further
functions of the printer logiJET TC8 can be found in the
following chapters.
4.2. Characteristics of the logiJET TC8
The rear print unit prints the first color (standard: black)
The front print unit prints the second color
Fig. 4.2.a Position of the print units
Front printhead
release lever


Rear printhead
release lever
Print direction
