Microplex LOGIJET TC8 - Continuous Media Handling; Media Loading

Handling of Consumables 29
_________________________________________________________________________________________
_________________________________________________________________________________________
Microplex logiJET TC8 Edition 1.2
5.1. Continuous Media Handling

The logiJET TC8 printer can be used for printing on roll-fed media as
well as for printing on fanfold media.
The center of every print media (paper) has to be aligned with the
center of the printhead, regardless of media (paper) width.
An output of the current printer values (including the currently set
paper size et
function (see section 7.8).
5.1.1. Media Loading
The printer is able to process formatted media and unformatted
media, too. The panel function to set the media is described in
section 7.1.
1. Turn the printer OFF LINE.
2. ion
(compare figure 5.1.1.a).

Top cover
of the printer
