Microplex LOGIJET TC8 - Paper Length Adjustment (Page Length)

Panel Functions 109
_________________________________________________________________________________________
_________________________________________________________________________________________
Microplex logiJET TC8 Edition 1.2
7.5. Paper Length Adjustment (Page Length)
Hints:
After inserting new material (e.g. paper) this function is used to adjust the printer to
the new paper length.
Alternatively, the printer itself is able to measure the label length. See next sections.
Please execute this length adjusting after you have successfully adjusted the Sync
sensors, the slip correction and the Sync.Sens.Offset (See previous sections).
Panel display
[ON LINE ]
[Menu Level 1 ]
  
[Paper Menu ]
[Paper Size ]
[Paper Length ]
[Measure Length ]
  
[in mm ]
  
[Digit4 149.9]
  
[Digit1 149.5]
[Save as Setup? ]
Notes
Turn the printer OFF LINE with this key.
Press the NEXT or PREVIOUS key until
[Paper Menu ] is displayed.
Press the ENTER key to select the paper
menu.
Press the ENTER key to select the paper size
menu.
Press the ENTER key to adjust the paper
length.
Press the NEXT or PREVIOUS key if you want
to adjust the paper length manually:
mm = currently selected measuring unit.
(Alternative the units inch or 1/300 inch can be
chosen with NEXT or PREVIOUS).
Pressing the NEXT or PREVIOUS key changes
the value of the current digit (Digit4 = left
position, in this example: 1). Pressing the
ENTER key moves you to the next digit (the
ESC key moves you back, if need be).
The paper length is changed to 149.5 mm.
In addition this new value can be saved as
setup value (using the ENTER key).
After this decision turn the printer ON LINE
again: Press the ONLINE key longer than 2
seconds.
