108 Panel Functions
_________________________________________________________________________________________
_________________________________________________________________________________________
Microplex logiJET TC8 Edition 1.2
feed direction
print material
Gap position
detected by
the printer,
zero-position
Fig. 7.4.a Adjusting the Zero Position of the Material Transport
Hint: The printer uses the sensors located at the rear print unit.
