Panel Functions 81
_________________________________________________________________________________________
_________________________________________________________________________________________
Microplex logiJET TC8 Edition 1.2
7.2. Adjusting the Sync Sensors
Please note: Always adjust the sensors of your printer to your consumables in use
(sensor positions as well as the levels and currents).
7.2.1. Checking and Adjusting the Position of the Sensors
The device is provided with sensors to enable controlling of consumable
movements (Synchronization).
The upper media sensor (Transparent sensor) as well as the lower media
s
Move the sensors to the accurate position (appropriate to your consumables):
Please note: The printer uses the sensors located at the rear print unit.
Always adjust all sensors of this print unit to your current consumables
(sensor positions and the levels and currents).
1.
2. Unlock the rear printhead assembly by pushing the printhead
release lever and raise the printhead assembly to a vertical
position.
3. Unlock the transparent sensor guide by pushing its lever and raise
the transparent sensor guide until it stops (as shown in figure
7.2.1.a and figure 7.2.1.b).
