82 Panel Functions
_________________________________________________________________________________________
_________________________________________________________________________________________
Microplex logiJET TC8 Edition 1.2
Fig. 7.2.1.a Unlocking the transparent sensor guide of the rear print unit
Fig. 7.2.1.b Rear printhead and transparent sensor guide raised

Transparent sensor
guide release lever
Rear printhead
already raised
Top cover
of the
printer
Upper sensor
(Transparent sensor)
Lower Sensor
(includes the
Reflex sensor)
