Panel Functions 83
_________________________________________________________________________________________
_________________________________________________________________________________________
Microplex logiJET TC8 Edition 1.2
4. Insert the consumables and set the paper guides to the paper width
(refer to section 5.1 for details).
5. Find out the position of the gaps/marks of your consumable.
6. The following table gives you an overview of print media and
sensor target positions (upper sensor = transparent sensor, lower
sensor = includes the reflex sensor):
Media
Sensors required
Sensor position mark
Media with Black marks
Lower sensor (Black mark)
(+ upper sensor for paper end
detection)
Directly over the black
mark
Die-cut label
Lower and upper sensor (Gap)
The middle of media
Center-punched hole tag
Lower and upper sensors (Gap)
Directly over the hole
Notched tag
Lower and upper sensors (Gap)
Directly over the notch
7. Set the lower sensors to the lateral position of the gaps or marks of
your material. (Compare the yellow arrows in the following figure.)
