Handling of Consumables 59
_________________________________________________________________________________________
_________________________________________________________________________________________
Microplex logiJET TC8 Edition 1.2
Fig. 5.2.4.c Unlocking the takeup mandrel to remove it
7. Lift the takeup mandrel from the gearwheel of the ribbon
drive mechanism.

Takeup
mandrel
Drive
mechanism
Printhead
assembly
