MIMAKI JV3-160SP User Manual

– 1.6 –
Item JV3-75SPII JV3-130SPII JV3-160SP JV3-130SL
Printing head Method Piezo-electric drop-on demand
Specification 4-heads Inlines 2-heads Inlines
Nozzle 360 nozzles for each color
Resolution 360, 540, 720, 1440 dpi
Drawing mode 4-color ink set 360 x 360 dpi : 1 / 2 / 4 passes, Unidirection / bidirection
360 x 540 dpi : 3 / 6 / 12 passes, Unidirection / bidirection
360 x 720 dpi : 2 / 4 / 8 passes, Unidirection / bidirection
720 x 720 dpi : 2/ 4 / 8 passes, Unidirection / bidirection
720 x 1440 dpi : 4 / 8 / 16 passes, Unidirection / bidirection
6-color ink set 360 x 360 dpi : 2 / 4 / 8 passes, Unidirection / bidirection
360 x 540 dpi : 3 / 6 / 12 passes, Unidirection / bidirection
360 x 720 dpi : 4 / 8 / 16 passes, Unidirection / bidirection
720 x 720 dpi : 4 / 8 / 16 passes, Unidirection / bidirection
720 x 1440 dpi : 8 / 16 / 32 passes, Unidirection /bidirection
1440 x 1440 dpi : 16 / 32 passes, Unidirection / bidirection
Usable inks Exclusive solvent inks :SS, MS2, SS2 any of 1 ink type
4 color set :(Black, Cyan, Magenta, Yellow x2) Each color x 1
6 color set :
(Black, Cyan, Magenta, Yellow, Light cyan, Light magenta x1
+2cleaning cartredges) 1 cartridge per color
Delivery system of ink Supplies ink through a tube from ink cartridge
Remaining ink display function (IC mounted)
Ink end detecting function
Ink cartridge replacement system
Capacity of ink cartridge
4 color set : each color (220 cc ± 5 cc per cartridge) x 2 SS2:220cc, 440cc SS2:220cc, 440cc
6 color set : each color (220 cc ± 5 cc per cartridge) x 1 ES3:220cc, 440cc
About 200 cc for each cartridge variable
Medium type Tarpaulin, FF, PVC
Max. printing Normal Scan 800mm 1361mm 1610mm 1361mm
width High-speed Scan 800mm 1321mm 1570mm 1321mm
1440 x 1440 dpi 800mm 1361mm
(4 colors) 1610mm
1000mm (6 colors)
Roll Medium Maximum 810 mm 1371mm 1620mm 1371mm
size Minimum 210 mm 210mm 210mm 210mm
Thickness 1.0 mm or less 1.0 mm or less 1.0 mm or less 1.0 mm or less
Roll outside diameter Ø 180 mm or less Ø 180 mm or less Ø 180 mm or less Ø 180 mm or less
Roll weight 15 Kg or less 25 Kg or less 25 Kg or less 25 Kg or less
Roll inside diameter 2 Inch, 3 Inch
Plotting surface Faces OUT
Roll end treatment Light-adhesive tape is used to allow the paper to be removed from the core
with ease.
Leaf medium Maximum 810 mm 1371mm 1620mm 1371mm
size Minimum 210 mm 210 mm 210 mm 210 mm
Margin Leaf medium Left end and right end : 15 mm
Front : 65 mm
Rear : 110 mm
Margin Roll medium Left end and right end : 15 mm
Front : 25 mm
1-5. Specifications
180 nozzles for each color
2 / 4 / 8 passes,
Unidirection / bidirection
4 / 8 / 16 passes,
Unidirection / bidirection
4 / 8 / 16 passes,
Unidirection / bidirection
8 / 16 / 32 passes,
Unidirection / bidirection
16 / 32 passes,
Unidirection / bidirection
SS, ES3 any of 1 ink type
*1 When the roll holder is set at the top position, the roll outside diameter is Ø140 mm or less.
*2 Without slack on the roll when it is retained at both ends.

MIMAKI JV3-160SP Specifications

General

Brand	MIMAKI
Model	JV3-160SP
Category	Plotter
Language	English
