MIMAKI JV3-160SP User Manual

– 5.13 –
5-3-3. WASH
[Function]
The ink that has been filled is ejected, and the tube, damper and head are cleaned with a
washing fluid. This process is normally carried out prior to shipment from the factory
[Operation]
1) Select the “ADJUSTMENT”.
Press the
ENTER
key.
2) Press the
FUNCTION
key to select the “
WASH.”
Press the
ENTER
key.
3) Detach the ink cartridge.
The ink that has been filled is ejected to the waste
ink tank.
4) When the display shown at left appears, set
the cleaning tool.
Cleaning fluid is suctioned up.
5) When the display shown at left appears,
remove the cleaning tool.
Suck in air.
6) When the display shown at left appears, set
the cleaning tool.
Cleaning fluid is suctioned up.
7) When the display shown at left appears,
remove the cleaning tool.
The waste ink tank discharges the cleaning fluid
sucked.
8) When the display shown at left appears,
cleaning the wiper and click the
ENTER
key.
9) Select whether cleaning is to be continued.
To end cleaning, press the
key.
FUNCTION
# ADJUST < ENT >
# ADJUST
WASH < ent >
WASH
REMOVE CARTRIDGE
WASH
SET CLEAN TOOL
WASH
REMOVE TOOL
WASH
SET CLEAN TOOL
WASH
REMOVE CARTRIDGE
WIPER CLEANING
COMPLETED : ent
WASH
END < > CONTINUE
