– 5.62 –
5-4-18. ENCODER CHECK
[Function]
Check linear sensor or linear encoder scale.
Based on capping position, indicate value of linear encoder and Y motor encoder when it’s
moved an optional position that was specified.
[Operation]
1) Select the “TEST”.
Press the
ENTER
key.
2) Select the “ENCODER CHECK” pressing the
FUNCTION
key.
Press the
ENTER
key.
3) The carriage indicates the maximum moving
distance. (Depend on plotter size)
4) Input the movement distance of carriage using
or key.
The value that is able to set up is decided 100
mm to max movement distance. (100 mm step)
5) Press the
ENTER
key
The carriage shuttles the set distance 3 times and
the linear encoder value and Y motor encoder
value are read.
If a difference (Es-Er) between back and forward
moving of the linear encoder reaches over ±3, then
error may cause and operation will be completed.
Indicate the following values when carriage was
returned to capping position.
[value that is moved a specified distance]
– [value of capping position before movement]
M : value of Y motor encoder (µm)
E : value of linear encoder (mm)
FUNCTION
# TEST < ENT >
# TEST
ENCODER < ent >
#ENCODER
DIST . : ∗ ∗ ∗ ∗. ∗ mm
#ENCODER
DIST . : ∗ ∗ ∗ ∗. ∗ mm
#ENCODER
M ∗ ∗ ∗ ∗. ∗ E ∗ ∗ ∗ ∗. ∗
To Next Page
