– 5.63 –
Return to Process No. 3 when press the
key.
It is normal if value of Y motor encoder and value
of linear encoder is indicated approximate.
There are appearance of dispersion of linear scale
and 2 mm to 3 mm gaps by stretching, though it
isn’t unusual.
If [500mm SQUARE] is not adjusted, pattern shift
becomes larger.
When (Ex-Er) reaches over ±3, the driving belt
get loose.
6) Press the
key. Indicate the calculation as
follows.
[value of capping position after movement]
– [value of capping position before movement]
Mc : value of Y motor encoder (µm)
Ec : value of linear encoder (mm)
It is normal if a difference of capping position
before and after that is moved is zero.
Press the
FUNCTION
key to display the
following values:
• Capping position value before movement
(resolution)
Ms : value of Y motor encoder (5µm)
Es : value of linear encoder (720dpi)
• Capping position value after movement over
the specified distance (resolution)
Mm : value of Y motor encoder (5µm)
Em : value of linear encoder (720dpi)
• Capping position value after movement
(resolution)
Mr : value of Y motor encoder (5µm)
Er : value of linear encoder (720dpi)
7) Return to process 5) when press the
key.
Return to process 3) when press the
key.
When press the
key after the above
operation, this test has ended.
# TEST
Mc 0 .0 Ec 0 .0
#ENCODER
M s ∗ ∗ ∗ ∗. ∗ E s ∗ ∗ ∗ ∗. ∗
#ENCODER
M m ∗ ∗ ∗ ∗. ∗ E m ∗ ∗ ∗ ∗. ∗
#ENCODER
M r ∗ ∗ ∗ ∗. ∗ E r ∗ ∗ ∗ ∗. ∗
