3-2. Error messages and corrective measures
3-2-1. Error messages for troubles for which error numbers are given on the LCD
1) Replace the main PCB with a
new one.
1) Replace the power supply or
the main PCB with a new one.
1) Replace the main PCB with a
new one.
1) Has ink in the camper run out?
2) Check the FPC cable connection.
3) Replace the Slider PCB with a new one.
4) Replace the head with a new one.
5) Replace the main PCB with a new one.
1) Replace the Linear encoder with
a new one.
2) Replace the main PCB with a
new one.
1) Replace the main PCB with a
new one.
1) Check the data received through
HEX dump.
2) If error occurs at 1394
a. Replace the 1394 board with
[E103898] .
b. Replace the main PCB with
[E102571] or [E103537].
c. Supply power to the 1394 PCI
board in the PC through the
power cable.
1) It is not used in the field.
• The control ROM is in
abnormal conditions.
• The control RAM is in
abnormal conditions.
• The +5V (+35V) voltage is in
abnormal conditions.
• The Flash memory is in
abnormal conditions.
• An error has occurred in the
D-RAM.
• Abnormal head temperature is
detected.
• The Linear encoder is in
abnormal conditions.
• Configuration of PDC/IOC
has not been successfully
carried out.
• Configuration of HDC has not
been successfully carried out.
• Command code other than
MRL has been received.
• Parameter that has not defined
in MRL has been received.
•A command error for
manufacture of has occurred.
Message Description
Corrective measures and
recovering procedures
ERROR01 MAIN ROM
ERROR02 MAIN RAM
ERROR03 POWER +5V
POWER +35V
ERROR04 FLASH ROM
ERROR06 D-RAM
ERROR07 HEAD --
*
-----
ERROR08 ENCODER
ERROR09 HDC
ERROR10 COMMAND
ERROR11 PARAMETER
ERROR12 Ment Command
