Mindray A7 Operating Instructions

Leak and Compliance Tests Preoperative Tests
4 - 10 046-004667-00 A7™ Operating Instructions
4.
RESULTS COMMENTS/OPTIONS
Automatic Circuit Leakage: Pass
Compliance Test: XX.X mL/cmH
2
O
Example:
Leak rate ≤200 ml/min
Compliance test results display in green.
Select Continue to proceed to the Manual Circuit Leak
Test screen.
Automatic Circuit Leakage: Pass
Compliance Test: Fail
Example:
Leak rate ≤200 ml/min
Compliance test failed.
The results screen displays the compliance values and
time of the last successful compliance test. Unsuccessful
compliance tests display compliance values and test time
as “---”.
Select Accept to proceed to the Manual Circuit Leak Test
screen and use the previous compliance values.
or
Select Retry to repeat the Automatic Circuit Leak Test &
Compliance test.
Automatic Circuit Leakage: XXX ml/min
Compliance Test: Fail
Example:
Leak rate >200 ml/min and ≤1000 ml/min
The results screen displays the compliance values and
time of the last successful compliance test. Unsuccessful
compliance tests display compliance values and test time
as “---”.
Select Accept to proceed to the Manual Circuit Leak Test
screen and use the previous compliance values.
or
Select Retry to repeat the Automatic Circuit Leak Test &
Compliance test.
TABLE 4-3 Automatic Circuit Leak and Compliance Test Results

Mindray A7 Specifications

General

Type	Anesthesia Workstation
Brand	Mindray
Model	A7
Display	15-inch color touchscreen
Oxygen Flush	Yes
Gas Inlets	O2, N2O, Air
Ventilation Modes	SIMV, PSV
Breathing System	Integrated
Gas Monitoring	O2, CO2, N2O
Monitoring Parameters	FiO2
CO2 Monitoring	Mainstream or Sidestream
Power Supply	100-240 V, 50/60 Hz
