A7™ Operating Instructions 046-004667-00 E - 7
Abbreviations, Symbols, and Units of Measure Attention Symbols
FIGURE E-2 Main Unit (Rear View)
ATTENTION!
NUMBER DESCRIPTION
04 Each auxiliary outlet is rated at 100 to 120 VAC @ 50/60 Hz.
05 Individual outlet current is limited to 3 A. Total mains output current is limited to 10 A.
06 Sample Line Exhaust Gas Inlet: Inlet for waste gas from an optionally attached gas
module. Merges with the AGSS connector that connects to the AGSS.
04
05
06
