A7™ Operating Instructions 046-004667-00 1 - 11
Product Description Physical Views
A24 Vaporizer Mounting Manifold /
Mounting Bar
An interface for two/three Selectatec-type vaporizers to
mount in this location. Bar holds two/three (optional)
vaporizers. An interlock within the vaporizers provides for
use of one vaporizer to deliver one agent at a time.
A25 Vaporizer Mount Valve
Cartridge
Vaporizer index and outlet ports.
A26 Vaporizer Parking Spot Holds a non-functional vaporizer for user convenience.
A27 Vaporizer Locking Device Vaporizer locking mechanism to secure against accidental
disconnection
A28 Pressure Gauges (pipeline) Indicate the pressure at pipeline inlets for O
2
, Air, and N
2
O.
A29 System Switch Switch to turn the system On or off.
A30 AC Status LED Illuminated when the system is connected to an AC power
source.
A31 Pressure Gauges (cylinder) Indicate the pressure at cylinder inlets for O
2
, Air, and N
2
O.
A32 Battery Charging LED Illuminated when the battery supply is charging.
A33 Handle Metal bar used to assist moving the A7
A34 Key lock Key and lock for securing the drawers
A35 Storage Drawers Drawers (3) for storage (lockable)
