Mindray A9 Service Manual

2-10
Part Description
C3
Module slot
FDA:
The module slot is used to install and identify the AG
module described in this manual.
Canada：
The module slot is used to install and identify the NMT,
AG, and BIS module described in this manual.
C4
Electronic AGSS flow
regulating knob
You can rotate the knob clockwise or counterclockwise
to adjust the flow in the AGSS, until the float on the
status display is between the Min and Max scales.
C5
Sample gas return port
A sample gas return port is provided for the gas module.
C6
Auxiliary high-pressure
O2 outlet
The outlet is used to connect to an external device, for
example, a jet ventilator.
C7
O2 sensor door cover
switch
The switch is used to open the O2 sensor door cover.
C8
Handle
The handle can bear maximum force of 10 kgf (22 lbf).
The handle is only used for disassembling the breathing
system, but not for pushing/pulling/lifting the anesthesia
machine.
C9
Handle
The handle is used for pushing/pulling/turning the
anesthesia machine. It can bear maximum force of 80 kgf
(176 lbf).

Mindray A9 Specifications

General

Type	Anesthesia Workstation
Integrated Gas Analysis	Yes
Backup Battery	Yes
Operating Temperature	10°C to 40°C
Storage Temperature	-20°C to 55°C
Battery Type	Lithium-ion
Ventilation Modes	Volume Control, Pressure Control, SIMV, Manual Ventilation
Display	Touchscreen
Patient Monitoring	ECG, SpO2, NIBP, EtCO2, Temperature
Connectivity	Ethernet, USB
Portability	Mobile (with wheels)
Battery Life	Minimum 90 minutes (typical)
Altitude	Up to 3000 meters
Power Supply	100-240 VAC, 50/60 Hz
Charging Time	Approximately 4 hours
Storage	Internal storage for patient data and system logs
Supported Languages	Multiple languages
Certifications	CE, FDA
