18-2
18.3 Unfreezing Waveforms
To unfreeze the frozen waveforms, you can either:
îš„ Select [Exit] in the [Freeze] menu,
îš„ Select the
hardkey on the monitor’s front, or
îš„ Perform any operation through which the screen will re-arrange or a menu will pop up,
such as plugging in or out a module, pressing the
hardkey, etc.
18.4 Recording Frozen Waveforms
1. In the [Freeze] menu, select, in turn, [Wave 1], [Wave 2] and [Wave 3] and then select
your desired waveforms.
2. Select the [Record] button. The selected waveforms and all numerics at the freeze time
are printed out by the recorder.
