Structure and Assembly/Disassembly 7-11
7.3 Preparations
7.3.1 Tools Required
Cross-headed screwdriver: 1pcs, Spec: 105 X100
Anti-static gloves: 1 pair
7.3.2 Engineers Required
Only technical professionals from Mindray or engineers authorized by Mindray after training
can perform maintenance and check.
7.3.3 Assembly/Disassembly Required
You should perform the following preparations before the disassembling of ultrasound equipment.
1. When you stop the scanning and the image capture, you should power off the system and
disconnect the system from the AC power supply, then pull out AC power cables.
2. Open the battery cover and removing battery.
3. Prepare Tools disassembled and anti-static gloves.
WARNING:
Please start to disassemble when you are sure that you have pull
battery out.
7.4 Assembly/Disassembly
This section describes the disassembling and assembling of the main modules and boards. The
assembling is the inverse process of disassembling if not mentioned in particular.
Sketch map
