System Installation 3-11
4. When the ultrasound system is working, information scanning can be performed by pressing
the switch on the scanner. For detailed operations, please refer to the operator’s manual of the
scanner.
5. Fix the scanner on the bracket (see the figure below) to avoid accidental falling.
2D scanner 1D scanner
3.5 System Configuration
3.5.1 Power ON / OFF
Connect the system power cord to the AC power, and make sure the ultrasound system and
other optional devices are correctly connected.
When the AC indicator is green, you can turn on the power button (located at the upper right
corner of the system) to initiate the system. After being normally rebooted, it will display image
interface. Or press the power button directly when the battery is of sufficient capacity.
3.5.2 Enter Doppler
After the system is powered on after initiation (about 30S), it enters Doppler directly:
