System Diagnosis and Support 8-1
8 System Diagnosis and
Support
8.1 General Status Indicator
8.1.1 Status Indicators of the Control Panel
Status
indicators
Icon
Status definition and indicators
Position
Power-on
status
indicator
The indicator is not on when the system is turned off;
Press the key, the indicator blinks green at power on.
After power on, the indicator is green.
The Control
Panel
on the upper
right corner
Battery
status
indicator
1.It illuminates in orange when battery is charging;
2. It illuminates in green when battery is charging to100%
electricity;
3. When the battery capacity is more than 20% in
discharging status, the green indicator blinks.
4. When the battery capacity is less than 20% in
discharging status, the orange indicator blinks; When less
than 10%, the orange indicator blinks quickly.
5. When the battery is in non-charging/discharging status
or no battery is in, the indicator is not on.
The Control
Panel
on the lower
left corner
AC
indicator
The indicator blinks on green when the system is
connected to the AC power supply. The indicator is not on
when battery supplied.
The Control
Panel
on the lower
left corner
Standby
status
indicator
The indicator blinks orange in standby status.
The indicator is off on the other status.
The Control
Panel
on the lower
right corner
Hard disk
indicator
The indicator light flashes in green when the hard disk is
reading or writing.
The indicator is off automatically in other situations.
The Control
Panel
on the lower
right corner
