Mindray Z6 Service Manual

3-6 System Installation
3.3.2 Control Panel Adjusting
Press the ① lock buttons on the both sides of the control panel as illustrated in the following
picture, open the control panel.
Figure 3-2 Control Panel Adjustment
3.3.3 Display Adjusting
1. Open the display as described in 3.3.2
2. Put the finger into the bottom of the display and pull the display to tilt the display (30
degrees max.)
3. Ear off the screen protective film.
Figure 3-3 Open and tilt the display
Press <Fn>+ directional keys to adjust brightness and contrast.
 Brightness Adjustment:
refer to the brightness control keys; press <Fn>+ to decrease the
brightness; and press <Fn>+ to increase the brightness.

Mindray Z6 Specifications

General

Brand	Mindray
Model	Z6
Category	Medical Equipment
Language	English
