Mindray Z6 Service Manual

Troubleshooting of Regular Malfunctions 10-5
No.
Descriptions
Remarks
1
1112 main board/1114 main board
2
1150 probe board/1151 probe board
10.4.2 Key Points Supporting Troubleshooting
No.
Key Points Supporting Troubleshooting
Remarks
1
Probe recognition of all models of probes when
connecting on the same or different ports
2
Probe board ID of the system
10.4.3 Troubleshooting
No.
Fault
Description
Cause Analysis
Measure
1
Probe cannot
be
recognized
This probe cannot be recognized by connecting to all
probe sockets, while reorganization of other probes is
normal. Probe malfunction.
Replace the probe.
This probe cannot be recognized when connecting to a
certain socket. Probe board malfunction.
Replace the probe
board
All probes cannot be recognized in all probe sockets;
Probe board ID cannot be read correctly by the system
information;
Main board or probe board malfunction.
Replace the main
board or probe
board.
10.5 IO Interface System
10.5.1 Module or Board Related
No.
Descriptions
Remarks
1
1112 main board/1114 main board
2
CPU module
3
IO board
4
1112 Speaker
