Mindray Z6 Service Manual

10-6 Troubleshooting of Regular Malfunctions
10.5.2 Key Points Supporting Troubleshooting
No.
Key Points Supporting Troubleshooting
Remarks
1
Working condition of the control panel
Confirm if the USB main device is functional
since the control panel is connected by internal
USB cable
2
Working condition of each USB port
See 2.1.1.2
3
Working condition of Video, S-video and
VGA video interfaces
See as above
4
Printing condition of video printer
Check if output of connected video printer is
normal
10.5.3 Troubleshooting
No.
Fault Description
Cause Analysis
Measure
1
LCD displays normally;
NO video printer output when
press <print> on control panel
Remote printing control failure
or video output failure if there is
no user-defined key failure.
Replace the main
board.
2
Two speakers have no sound
Main board malfunction
Replace the main
board
3
Only one speaker has no sound
Speaker malfunction
Replace speaker
4
USB device cannot be
recognized while connecting to
the USB port
Control panel works well
Main board malfunction
Replace the main
board.
5
Network disconnected or
abnormal
CPU module or IO board
malfunction if there is no
network or setting failure.
Confirm by replacing
CPU module or IO
board.
10.6 Control Panel
10.6.1 Module or Board Related
No.
Descriptions
Remarks
1
1112 silicon key
2
Control panel
3
Dual encoder module
4
Single encoder module
