System Installation 3-9
Figure 3-6 Installing Analog Video Printer
Digital Video Printer
1. Connect one terminal of the data cable of the video printer to the USB port of the
ultrasound system and the other terminal to the video input port of the video printer;
2. Insert the power cord to a power supply receptacle that is well grounded.
3. Please refer to 3.5.4 for the driver installation. And you need not install the driver of the
printer listed in section “2.1.3”.
3.4.3 Installing a Graph / Text Printer
A graph / text printer is configured with power cord and data cable, and is connected to the
system via the USB port. The connection method is described as follows:
1. Connect the data cable to the USB port in the ultrasound system.
2. Plug the power plug into a power supply receptacle that is well grounded.
3. Please refer to 3.5.4 for the driver installation. And you need not install the driver of the printer
listed in section “2.1.3”.
3.4.4 Installing External DVD-R/W
1. Connect the USB cable connector of the external DVD recorder to the USB port in the
ultrasound system;
To Next Page
