2) Remote output
4 stations occupied (CSD-892-73 → Master)
Device No. Contents Classification
RYn0 ① Setting value writing request (Request 1)
Communication
RYn1
RYn2 ② General command request (Request 2)
RYn3 ③ Selection of writing/Reading out. (R/W)
RYn4 ④ Operation mode changeover request (Request 3)
RYn5
RYn6 ⑤ Normal operation of CPU
RYn7
RYn8 ⑥ Decimal point 1
RYn9 ⑥ Decimal point 2
RYnA ⑥ Decimal point 4
RYnB
RYnC
RYnD
RYnE
RYnF
RY(n+1)0 ⑦ Near Z
ero
Control signal
RY(n+1)1 ⑦ Full flow/S1
RY(n+1)2 ⑦ Medium flow/S2
RY(n+1)3 ⑦ Dribble flow/S3
RY(n+1)4 ⑦ Over/S4
RY(n+1)5 ⑦ OK/S0
RY(n+1)6 ⑦ Under
RY(n+1)7 ⑦ Stable
RY(n+1)8
RY(n+1)9 ⑧ Weight value over
RY(n+1)A ⑨ During HOLD
RY(n+1)B ⑦ Full
RY(n+1)C
RY(n+1)D
RY(n+1)E
RY(n+1)F ⑩ Abnormal weight
RY(n+2)0
RY(n+2)1
RY(n+2)2
~
RY(n+7)0
System reservation flag
RY(n+7)1
RY(n+7)2
RY(n+7)3
RY(n+7)4
RY(n+7)5
RY(n+7)6
RY(n+7)7
RY(n+7)8
RY(n+7)9 ⑪ Initial data se
tting complete flag
RY(n+7)A ⑫ Error condition flag
RY(n+7)B ⑬ Remote ready flag
RY(n+7)C
RY(n+7)D
RY(n+7)E
RY(n+7)F
n : Value decided by setting of station No.
95
CC-Link
