14-3-2. Station number
The station number for CC-Link communication is set by function F-85.
Setting range : 01 ~ 64
：01
When 1 station is occupied : Select from station number 01 ~ 64
When 2 stations are occupied : Select from station number 01 ~ 63
When 4 stations are occupied : Select from station number 01 ~ 61
Numbers of occupied station of this unit is 1, 2 or 4 stations.
14-3-3. Baud rate (Communication speed)
The baud rate (unit : bps) for CC-Link communication is set by function F-86.
Setting range：0 ~ 4
0：156kbps
1：625kbps 2：2.5Mbps
3：5Mbp 4：10Mbps
14-3-4. 32 bit data indication method
32 bit data indication method for CC-Link communication is set by function F-87.
Setting range：0,1
0：Indication by standard binary
1：Highest bit sign (Highest-order digit 8 is fixed negatively.)
Load value 32 bit data indication method Upper 16 bit Lower 16 bit
-1
Indication of standard binary FFFFH FFFFH
Highest bit sign 8000H 0001H
-10
Indication of standard binary FFFFH FFF6H
Highest bit sign 8000H 000AH
-99999
Expression of standard binary FFFEH 7961H
Highest bit sign 8001H 869FH
• When 2 stations are occupied and station No. is set as [01]
: No. 01 ~ 02 is occupied.
• When 4 stations are occupied and station No. is [01]
: No. 01 ~ 04 is occupied.
Therefore, the station number must not overlap.
• The setting of station number is confirmed by allocating the CC-Link station
number confirmation function to [F/ENTER] key.
Please refer [8-7. Operation of F/ENTER key] for the
details.
79
