About SMB Controller
Stranded
element
Core color Cable
designation
RJ45
Pin
Port
Two-wire
connection
violet 6 x.2b
white 1 x.3a
orange 2 x.3b
turquoise 7 x.4a
8
violet 8 x.4b
Prefabricated system cable 12 x RJ45
The cable is 6 m long and, at one extremity, has 12 RJ45 connectors for the interfaces on the
front panel. Two of them have 4 cores; the others, 2 cores. This means the cable is suitable for
connecting the following interfaces:
•
10 terminal interfaces (DSI, or FXS) or a combination thereof.
Note:
This cable cannot be used to connect Ethernet interfaces. For Ethernet interfaces,
use standard commercial connecting cables.
Document Version 1.0
System Manual for Mitel SMB Controller 56
