4 - 6
4.3 Part Names
4
SETUP AND PROCEDURES BEFORE OPERATION
(3) Connector for external wiring
The connectors for use with the A/D converter module should be purchased sepa-
rately by the user.
The following tables show the connector types and the crimp-contact tool.
(a) Connector types
*1
*1: The A6CON3 (pressure-displacement type, straight out) connector cannot be used for the A/D con-
verter module.
(b) Crimp-contact tool
(1) Q68AD-G (2) Q66AD-DG
Terminal
number
Signal name
Terminal
number
Signal name
Terminal
number
Signal name
Terminal
number
Signal name
A1 CH1 V + B1 CH1 V -/I - A1 CH1 P B1 CH1 I +/CHK +
A2 CH1 I + B2 - A2 - B2 CH1 I -/CHK -
A3 - B3 CH2 V + A3 - B3 -
A4 CH2 V -/I - B4 CH2 I + A4 CH2 P B4 CH2 I +/CHK +
A5 - B5 - A5 - B5 CH2 I -/CHK -
A6 CH3 V + B6 CH3 V -/I - A6 - B6 -
A7 CH3 I + B7 - A7 CH3 P B7 CH3 I +/CHK +
A8 - B8 CH4 V + A8 - B8 CH3 I -/CHK -
A9 CH4 V -/I - B9 CH4 I + A9 - B9 -
A10 - B10 - A10 CH4 P B10 CH4 I +/CHK +
A11 CH5 V + B11 CH5 V -/I - A11 - B11 CH4 I -/CHK -
A12 CH5 I + B12 - A12 - B12 -
A13 - B13 CH6 V + A13 CH5 P B13 CH5 I +/CHK +
A14 CH6 V -/I - B14 CH6 I + A14 - B14 CH5 I -/CHK -
A15 - B15 - A15 - B15 -
A16 CH7 V + B16 CH7 V -/I - A16 CH6 P B16 CH6 I +/CHK +
A17 CH7 I + B17 - A17 - B17 CH6 I -/CHK -
A18 - B18 CH8 V + A18 - B18 -
A19 CH8V -/I - B19 CH8 I + A19 24VDC B19 24VDC
A20 - B20 - A20 24GDC B20 24GDC
P : Power supply for 2-wire transmitter
I+/CHK+ : 2-wire transmitter current input,
Current(+) input / check (+) terminal
I-/CHK- : Current(-) input / check (-) terminal
Type Model name Applicable wire size
Soldering type
(straight out)
A6CON1
0.3mm
2
(AWG22) (stranded)
Crimp-contact type
(straight out)
A6CON2
0.088mm
2
to 0.24mm
2
(AWG28 to
24) (stranded)
Soldering type
(straight out/diagonal out)
A6CON4
0.3mm
2
(AWG22) (stranded)
Type Model name Applicable wire size Contact
Crimp-contact tool FCN-363T-T005/H
0.088mm
2
to
0.24mm
2
(AWG26 to 24)
FUJITSU COMPONENT
LIMITED
http://www.fcl.fujitsu.com/
en/
B20
Seen from the front
of the module
B19
B18
B17
B16
B15
B14
B13
B12
B11
B10
B9
B8
B7
B6
B5
B4
B3
B2
B1
A20
A19
A18
A17
A16
A15
A14
A13
A12
A11
A10
A9
A8
A7
A6
A5
A4
A3
A2
A1
