7 - 19
7.3 Online Module Change Procedure
7.3.3 When user range setting is used and initial setting was made with GX Configurator-AD (other system
7
ONLINE MODULE CHANGE
(d) Monitor CH digital output values (Un\G11 to Un\G18) to check if the conversion
is processed normally.
(5) Resumption of control
(a) After choosing [Diagnosis] - [Online module change] on GX Developer to
redisplay the "Online module change" window, click the [Execution] button to
resume control. Module ready (X0) turns on.
(b) The "Online module change completed" window appears.
