8.1 Error Code List
8
TROUBLESHOOTING
Table 8.1 Error code list (3/3)
Error code
(decimal)
Error description Processing
6
*3
The process alarm upper/lower limit value (Un\G86 to Un\G117)
are set contradictorily.
indicates the channel number set incorrectly.
indicates the following state.
2: Lower lower limit value > lower upper limit value
3: Lower upper limit value > upper lower limit value
4: Upper lower limit value > upper upper limit value
Reset the contents of the process alarm upper/
lower limit values (Un\G86 to Un\G117).
70
*3
The rate alarm warning detection period (Un\G118 to Un\G125) is
outside the range of 10 to 5000ms.
indicates the channel number set incorrectly.
Reset the rate alarm warning detection period
(Un\G118 to Un\G125) to within 10 to 5000ms.
71
*3
The rate alarm warning detection period (Un\G118 to Un\G125) is
not:
• A multiple of the sampling cycle or
• A multiple of the time or count averaging conversion cycle.
indicates the channel number set incorrectly.
Change the value of the rate alarm warning detec-
tion period as follows:
• For sampling processing: A multiple of conver-
sion cycle (10ms x No. of conversion-enabled
channels)
• For averaging processing: A multiple of time or
count averaging conversion cycle
72
*3
When the time or count averaging setting in Un\G1 to Un\G8 is
changed, the rate alarm warning detection period is not a multiple
of the corresponding new time or count averaging conversion
period.
indicates the channel number set incorrectly.
Reset the time averaging or count averaging set-
ting so that the corresponding rate alarm warning
detection period is a multiple of the time or count
averaging conversion period.
80
*3
When the "Same upper limit value/lower limit value" is selected for
the input signal error detection extended setting,
• CH input signal error detection setting value (Un\G142 to
Un\G149) is outside the range of 0 to 250.
indicates the channel number set incorrectly.
Reset the input signal error detection setting value
to within 0 to 250.
When the "Different upper limit value/lower limit value" is selected
for the input signal error detection extended setting,
• Input signal error detection lower limit setting value (Un\G142 to
Un\G149) is outside the range of 0 to 251.
• Input signal error detection upper limit setting value (Un\G150 to
Un\G157) is outside the range of 0 to 251.
indicates the channel number set incorrectly.
Reset the input signal error detection lower limit
setting value and input signal error detection upper
limit setting value within 0 to 251.
90
*3
The scaling upper/lower limit value (Un\G62 to Un\G77) is set out-
side the range of –32000 to 32000.
indicates the channel number set incorrectly.
Correct the scaling upper/lower limit value within
the range of –32000 to 32000.
91
*3
In the scaling upper/lower limit value setting (Un\G62 to Un\G77),
Lower limit Upper limit.
indicates the channel number set incorrectly.
Set them again so that he scaling upper limit value
is greater than the scaling lower limit value.
To Next Page
