App - 9
APPENDIX
Control data of Q68AD-G
Device Item Set data Setting range Set by
(S) System area — — —
(S) + 1 Completion status
Stores the status when the instruction is
complete.
0 : Normal completion
Other than 0: Abnormal completion
—System
(S) + 2 Pass data classification setting
The value set to Pass data classification
setting (S)+2 using the G.OGLOAD instruc-
tion is stored.
0: Voltage specified
1: Current specified
0000
H to 00FF H System
(S) + 3 System area — — —
(S) + 4 CH1 Industrial shipment settings offset value — — System
(S) + 5 CH1 Industrial shipment settings gain value — — System
(S) + 6 CH2 Industrial shipment settings offset value — — System
(S) + 7 CH2 Industrial shipment settings gain value — — System
(S) + 8 CH3 Industrial shipment settings offset value — — System
(S) + 9 CH3 Industrial shipment settings gain value — — System
(S) + 10 CH4 Industrial shipment settings offset value — — System
(S) + 11 CH4 Industrial shipment settings gain value — — System
(S) + 12 CH5 Industrial shipment settings offset value — — System
(S) + 13 CH5 Industrial shipment settings gain value — — System
(S) + 14 CH6 Industrial shipment settings offset value — — System
(S) + 15 CH6 Industrial shipment settings gain value — — System
(S) + 16 CH7 Industrial shipment settings offset value — — System
(S) + 17 CH7 Industrial shipment settings gain value — — System
(S) + 18 CH8 Industrial shipment settings offset value — — System
(S) + 19 CH8 Industrial shipment settings gain value — — System
(S) + 20 CH1 user range settings offset value — — System
(S) + 21 CH1 user range settings gain value — — System
(S) + 22 CH2 user range settings offset value — — System
(S) + 23 CH2 user range settings gain value — — System
(S) + 24 CH3 user range settings offset value — — System
(S) + 25 CH3 user range settings gain value — — System
(S) + 26 CH4 user range settings offset value — — System
(S) + 27 CH4 user range settings gain value — — System
(S) + 28 CH5 user range settings offset value — — System
(S) + 29 CH5 user range settings gain value — — System
(S) + 30 CH6 user range settings offset value — — System
(S) + 31 CH6 user range settings gain value — — System
(S) + 32 CH7 user range settings offset value — — System
(S) + 33 CH7 user range settings gain value — — System
(S) + 34 CH8 user range settings offset value — — System
(S) + 35 CH8 user range settings gain value — — System
0
0 CH8 CH7 CH6 CH5
b15 b8 b7 b6 b5 b4
CH4 CH3 CH2 CH1
b3 b2 b1 b0
To Next Page
