APPENDIX
App - 10
APPENDIXINDEX
*2 Setting is not necessary. If setting is made, the offset/gain values will not be read properly.
Control data
*2
of Q66AD-DG
Device Item Set data Setting range Set by
(S) System area — — —
(S) + 1 Completion status
Stores the status when the instruction is
complete.
0 : Normal completion
Other than 0: Abnormal completion
—System
(S) + 2
System area — — —
(S) + 3
(S) + 4 CH1 Industrial shipment settings offset value — — System
(S) + 5 CH1 Industrial shipment settings gain value — — System
(S) + 6 CH2 Industrial shipment settings offset value — — System
(S) + 7 CH2 Industrial shipment settings gain value — — System
(S) + 8 CH3 Industrial shipment settings offset value — — System
(S) + 9 CH3 Industrial shipment settings gain value — — System
(S) + 10 CH4 Industrial shipment settings offset value — — System
(S) + 11 CH4 Industrial shipment settings gain value — — System
(S) + 12 CH5 Industrial shipment settings offset value — — System
(S) + 13 CH5 Industrial shipment settings gain value — — System
(S) + 14 CH6 Industrial shipment settings offset value — — System
(S) + 15 CH6 Industrial shipment settings gain value — — System
(S) + 16
System area — — —
to
(S) + 19
(S) + 20 CH1 user range settings offset value — — System
(S) + 21 CH1 user range settings gain value — — System
(S) + 22 CH2 user range settings offset value — — System
(S) + 23 CH2 user range settings gain value — — System
(S) + 24 CH3 user range settings offset value — — System
(S) + 25 CH3 user range settings gain value — — System
(S) + 26 CH4 user range settings offset value — — System
(S) + 27 CH4 user range settings gain value — — System
(S) + 28 CH5 user range settings offset value — — System
(S) + 29 CH5 user range settings gain value — — System
(S) + 30 CH6 user range settings offset value — — System
(S) + 31 CH6 user range settings gain value — — System
(S) + 32
System area — — —
to
(S) + 35
To Next Page
