3 - 21
3.2 Function List
3.2.3 Input signal error detection function
3
SPECIFICATIONS
The following table lists the lower limit value, offset value, and gain value for each
input range
Table3.4 The lower limit value, offset value, and gain value for each input range (Q68AD-G)
Input Analog input range Lower limit value Offset value Gain value
Volt-
age
0 to 10V 0V 10V
0 to 5V 0V 5V
1 to 5V 1V 5V
1 to 5V (extended mode) 1V 5V
-10 to 10V -10V 0V 10V
User range setting
Analog value when the digital value is:
• -4000 (normal resolution mode)
• -12000 (high resolution mode)
Analog value set as an
offset value by the user
Analog value set as a
gain value by the user
Cur-
rent
0 to 20mA 0mA 0mA 20mA
4 to 20mA 4mA 4mA 20mA
4 to 20mA (extended mode) 4mA 4mA 20mA
User range setting
Analog value when the digital value is:
• -4000 (normal resolution mode)
• -12000 (high resolution mode)
Analog value set as an
offset value by the user
Analog value set as a
gain value by the user
Table3.5 The lower limit value, offset value, and gain value for each input range (Q66AD-DG)
Input Analog input range Lower limit value Offset value
0 to 20mA 0mA 20mA
4 to 20mA 4mA 20mA
4 to 20mA (extended mode) 4mA 20mA
User range setting Analog value set as an offset value by the user
Analog value set as a
gain value by the user
