[2] Making the interlocking action settings
(1) Setting an Output Unit Type and Actions
Select an Output Unit Type and set the Actions, referring to the table below.
Table: Interlocking action settings
Output Unit
Type
Output
unit icon
Actions
Setting item
*2
Setting options
Group
ON/OFF ON, OFF
Mode
*1
Air conditioning unit group:
Cool, Dry, Fan, Heat, Auto, Setback
*3
LOSSNAY unit group:
Bypass, Heat Recovery, Auto
Set Temp.
*1
Desired temperature
Air direction
*1
Mid3, Mid2, Mid1, Mid0, Horizontal, Swing, Auto
Fan speed
*1
Low, Mid2, Mid1, High, Auto
Prohibit Remote Controller
Operation (ON/OFF)
Permit, Prohibit
Prohibit Remote Controller
Operation (Mode)
Permit, Prohibit
Prohibit Remote Controller
Operation (Set Temp.)
Permit, Prohibit
Free Output
Points
ON/OFF ON, OFF
*1 The available setting options vary, depending on the connected indoor unit model.
Make the interlocking action settings that are available for the output units.
*2 Only the items “ON/OFF” and “Prohibit Remote Controller Operation (ON/OFF and Set Temp.)” can be selected for Air To Water
(PWFY) units. Only the item “ON/OFF” can be selected for HWHP (CAHV, CRHV) units.
*3 The Setback mode can be selected on the AE-200A/AE-50A/EW-50A, but not on the AE-200E/AE-50E/EW-50E.
