(2) In the [Temperature display] section, select the desired display option for the room temperature or the set
temperature to be used on the [Floor] or [Block] display.
Select [Room temp. (Always)] to display the room temperature at all times, [Room temp. (During operation)]
to display the room temperature only during operation, [Set temp.] to display the set temperature at all times,
[Room temp.(Always)/Set temp.] to display both the room temperature and set temperature at all times, [Room
temp.(During op.)/Set temp.] to display the room temperature only during operation and to display the set
temperature at all times, and [Hide] not to display the room temperature or the set temperature.
Note: This setting is effective only on the LCD and will not be reflected to the Integrated Centralized Control Web.
Note: The room temperature shown may be higher than the actual temperature especially when the unit is stopped during
the Heat mode. Therefore, selecting [Room temp. (During operation)] is recommended when displaying the room
temperature.
(3) In the [Humidity] section, make the Show/Hide setting for the humidity reading of the built-in humidity sensor
on the ME remote controller (North America: PAR-U01MEDU, Europe: PAR-U02MEDA).
Select [ON] to display the humidity reading on the [Floor] or [Block] display.
Note: The table below summarizes the items that are displayed on the Monitor/Operation screen according to the combination
of the settings for “Temperature display” and “Humidity.”
Humidity
Temperature display
[Room temp. (Always)]
or
[Room temp. (During
operation)]
[Set temp.]
[Room temp.(Always)/
Set temp.]
or
[Room temp.(During op.)/
Set temp.]
Hide
OFF
Upper: Room temp.
Lower: N/A
Upper: Set temp.
Lower: N/A
Upper: Room temp.
Lower: Set temp.
Upper: N/A
Lower: N/A
ON
Upper: Room temp.
Lower: Humidity
Upper: Set temp.
Lower: Humidity
Upper: Room temp.
Lower: Set temp.
Upper: N/A
Lower: Humidity
