15. Press Max Tx Level. Enter 30 dBm and press Max Tx Level.
16. Press Access Parameter. Enter -53 dBm and press Access Parameter.
17. Press Test Mode → Enable.
18. Press Base Service.
NOTE: You are entering base services setup. The displayed value are factory defaults and
should not be changed.
Power On Registration: Required
Power Off De-registration: Required
Priority Cell: Yes
Minimum Mode Service: May Be Used
Migration: Supported
System Wide Services: Normal Mode
19. Press More.
TETRA Voice Service: Supported
Circuit Mode Data Service: Supported
(Reserved): Available
SNDCP Service: Available
Air Interface Encryption: Not Available
Advanced Link: Not Supported
20. Press Return. Select Neighbor Cell.
21. Verify that the following NEIGHBOUR CELL INFO values are displayed:
NOTE: The displayed values are factory defaults and should not be changed.
BROADCAST: Not Required
BROADCAST INTERVAL: 5 s
NEIGHBOUR CELL CHANNEL: 3500
NEIGHBOUR CELL LOCATION AREA: 00017
NEIGHBOUR CELL IDENTIFIER: 01
SLOW RE-SELECT THRESHOLD ABOVE FAST: 10 dB
22. Press More.
FAST RE-SELECT THRESHOLD: 10 dB
SLOW RE-SELECT HYSTERESIS: 10 dB
FAST RE-SELECT HYSTERESIS: 10 dB
23. Press Return.
24. Press Trunk Type → message Trunked (Transmission).
25. Press More.
NOTE: The displayed values are factory defaults and should not be changed. It is not required
to configure Call Types, Call Arial, and Messages.
26. Press More.
4.6
Configuring IFR 3901/IFR 3902/IFR 3920 Manual
Screen Test
Use these procedures to configure the IFR 3901/IFR 3902/IFR 3920 manual screen test.
Procedure:
1. Press TEST → TAB.
68015000841-EL
Chapter 4: Test Setup and Testing
48
