Test Name Test Setup Radio Setup Test Conditions Limits
Vector Error N/A N/A Max 10% RMS,
30% Peak
Frequency Error N/A N/A ±100 Hz
Call Processing
Talk Back
1 kHz Test Signal
Group Mode
N/A –50 dBm N/A
Call Processing
Call to Mobile
Private 4 digit random
number and Send
N/A 28–32 dBm
(Class 4)
30.5–34.5 dBm
(Class 3L)
RF Gen Level
Burst Power
N/A –90 dBm 28–32 dBm
(Class 4)
30.5–34.5 dBm
(Class 3L)
Timing Error N/A N/A ±0.25 Symbols
Vector Error N/A N/A Max 10% RMS,
30% Peak
Frequency Error N/A N/A ±100 Hz
4.3.1
Transmitter Tests
1. Power Burst (Control Range)
2. Power Profiles
3. Tx Burst Timing Error
4. Vector Error RMS and Peak
5. Tx Frequency Error
4.3.2
Call Processing Tests
1. Talk Back
2. Call to Mobile
4.3.3
Duplex Test
Digital Duplex Test (Tx)
Measurement Capabilities:
● Bar charts (Tx Power, Frequency Error, Vector Error RMS)
● Spectrum Analyzer
● Power Analyzer
● Vector Analyzer
68015000841-EL
Chapter 4: Test Setup and Testing
45
