RECEIVER
Intermodulation: (3.5%) BER
Interfering Signal Level –47 dBm
Selectivity Blocking:
(50–100 kHz)
(3.5%) BER
Interfering Signal Level –40 dBm
Spurious Rejection: (3.5%) BER
Interfering Signal Level –45 dBm
Frequency Stability:
Locked to Base +100 Hz
Unlocked to Base +1000 Hz
Audio Rated 2 W
Distortion at Rated Audio: 15% Max.
Table 18: Transmitter Specifications
TRANSMITTER
Modulation Type: π/4DQPSK
RF Power: Class 4
Class 3L
Class 3
Frequency Range:
TMO 350–470 MHz
DMO 350–470 MHz
Frequency Stability:
Locked to Base: +100 Hz
Unlocked to Base: +1000 Hz
Spurious Emissions:
Conducted
30 MHz–1 GHz:
1 GHz–12.75 GHz:
–36 dBm
–30 dBm
Radiated
30 MHz–1 GHz:
1 GHz–12.75 GHz:
–36 dBm
–30 dBm
Adjacent Channel Power (at ±25 kHz):
Class 4 (1 W) 55 dBc
Class 3L (1.8 W) 60 dBc
Class 3 (2.8 W) 60 dBc
68015000841-EL
Chapter 1: Model Information
31
