Any rework or repair on Environmentally Preferred Products must be done using the appropriate lead-free
solder wire and lead-free solder paste. These requirements are stated in the following tables:
Table 31: Lead Free Solder Wire Part Number List
Motorola Sol-
utions Part
Number
Alloy Flux Type Flux Content
by Weight
Melting
Point
Supplier
Part
number
Diame-
ter
Weight
1088929Y01 95.5Sn/3.8Ag/0.7Cu RMA Version 2.7–3.2% 217 °C 52171 0.015 in. 1 lb
spool
Table 32: Lead Free Solder Paste Part Number List
Motorola
Solutions
Part Number
Manufacturer
Part Number
Viscosity Type Composition
and Percent
Metal
Liquid Tem-
perature
1085674C03 NC-SMQ230 900–1000KCPs
Brookfield (5
rpm)
Type 3
(-325/+500)
(95.5%Sn-3.8%A
g-0.7%Cu)
89.3%
217 °C
Parts Replacement and Substitution
When damaged parts are replaced, identical parts must be used. If the identical replacement part is not
locally available, check the parts list for the proper Motorola Solutions part number and order the part.
Rigid Circuit Boards
This family of radios uses bonded, multilayer, printed circuit boards. Special considerations are required when
soldering and desoldering components as the inner layers are not accessible. The plated-through holes may
interconnect multiple layers of the printed circuit. Therefore, exercise care to avoid pulling the plated circuit
out of the hole.
When soldering near a connector:
● Avoid accidentally getting solder in the connector.
● Be careful not to form solder bridges between the connector pins.
● Examine your work closely for shorts due to solder bridges.
For soldering components with Hot-Air or infrared solder systems, check the user guide of your solder system
to get information on solder temperature and time for the different housings of the integrated circuits and
other components.
Care After Submersion
The radio (device with antenna and battery assembled) is IP67 compliant. It is fully protected from dust, and
can withstand being submerged up to 30 minutes in one meter of static water.
