Figure 10: Back Chassis Assembly (Plain) – Part No. 0104054J35
44
Figure 11: Encryption IC Exploded View
51
49
50
5.9.1.1
MTP3000 Series Full Keypad Radios Replacement Parts List
Table 35: MTP3000 Series Full Keypad Radios Replacement Parts List
No. Part/Kit Number Description Remark
1 42012047001 LCD retainer Serviceable. Bend the
side latches to 90° angle
after servicing and before
assembly.
68015000841-EL
Chapter 5: Maintenance
78
